MANUFACTURER OF STAINLESS STEEL 347H FLANGES | ASTM 182 STAINLESS STEEL 347H FLANGES | ASTM 240 STAINLESS STEEL 347H FLANGES | ANSI/ASME B16.1 STAINLESS STEEL 347H FLANGES
STAINLESS STEEL 347H FLANGES Exporter | STAINLESS STEEL 347H FLANGES Supplier | STAINLESS STEEL 347H FLANGES Manufacturer
UNIFLEX INDIA are one of the principle producers and exporters of unrivalled quality STAINLESS STEEL 347H FLANGES, These STAINLESS STEEL 347H FLANGES in run of the typical particulars, which finds applications in high requesting for business undertakings and divisions, particularly high temperature and acidic organizations. Our STAINLESS STEEL 347H FLANGES are strong, tough and at standard with overall quality and wellbeing models. We are powerful in offering our reputed clients with biggest quality STAINLESS STEEL 347H FLANGES . Our offered STAINLESS STEEL 347H FLANGES are produced using high survey tough steel as the crude material to ensure tip top and whole deal usage. Further, these 347H FLANGESare comprehensively used as machined parts, pump shafts, valves, clasp and handles.
Stainless Steel 347H Forged Flanges, Stainless Steel 347H Blind Flanges, Stainless Steel 347H Reducing Flanges, Stainless Steel 347H Orifice Flanges, Stainless Steel 347H Socket Weld Flanges, Stainless Steel 347H Slip On Flanges, Stainless Steel 347H Flat Flanges, Stainless Steel 347H Lapped Joint Flanges, Stainless Steel 347H SWRF Flanges, Stainless Steel 347H Square Flanges, Stainless Steel 347H Threaded Flanges, Stainless Steel 347H Weld Neck Flanges Series A or B, Stainless Steel 347H WNRF Flanges, Stainless Steel 347H Expander Flanges, Stainless Steel 347H High Hub Blinds Flanges, Stainless Steel 347H Spectacle Blinds Flanges, Stainless Steel 347H Loose Flanges, Stainless Steel 347H RTJ Flanges, Stainless Steel 347H Screwed Flanges, Stainless Steel 347H Weld Neck Flanges, Stainless Steel 347H Flange Facing Type & Finish, Stainless Steel 347H SORF Flanges, Stainless Steel 347H Groove & Tongue Flanges, Stainless Steel 347H Long Neck Weld Flanges, Stainless Steel 347H Spades Ring Spacers Flanges, Stainless Steel 347H Ring Type Joint Flanges, Stainless Steel 347H Weldo / Nipo Flanges.
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
|---|---|---|---|---|---|---|---|
| BS | En | No | Name | ||||
| 347H | S34709 | 304S31 | 58E | 1.4961 | X5CrNi18-10 | 2332 | SUS 347H |
| These comparisons are approximate only. The list is intended as a comparison of functionally similar materials not as a schedule of contractual equivalents. If exact equivalents are needed original specifications must be consulted | |||||||
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 347H | 515 | 205 | 35% | 95 | 21 |
| Designation | A 182 / A 240, SA 182 / SA 240 |
|---|---|
| Class | 150#, 300#, 400#, 625#, 900#, 1500# & 2500# |
| Size | 1/2″ NB TO 48″ NB |
| Standards | ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings, ASTM, ASME Flanges, ANSI Flanges, DIN Flanges, EN Flanges, BS Flanges etc. |
| Grade | A 182 347H |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 347H | min. | 0.04 | – | – | – | – | 17.0 | 3.00 | 9.0 | – |
| max. | 0.10 | 2.00 | 0.75 | 0.045 | 0.03 | 19.0 | 4.00 | 13.0 | 0.10 | |
| Density lbm/in3 |
Coefficient of Thermal Expansion (min/in)-°F |
Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)2-psi | |
|---|---|---|---|---|---|
| at 68 °F | at 68 – 212°F | at 68 – 1832°F | 68-932°F | at 32 – 212°F | in tension (E) |
| 0.288 | 9.2 | 11.4 | 14.7 | 0.12 | 28 x 106 |
